LONCIN G200F User Manual

OPERATION
-9-
2. Turn the engine switch to the OFF position.
3. Turn the fuel valve lever to the OFF position.
SETTING ENGINE SPEED
Position the throttle lever for the desired engine speed.
Some engine applications use a remotely-mounted throttle control rather than the
engine-mounted throttle lever shown here.
For engine speed recommendations, refer to the instructions provided with the equipment
powered by this engine.
ENGINE SWITCH
OFF
ON
FUEL VALVE
LEVER
OFF
THROTTLE LEVER
SLOW
FAST

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
