LONCIN G200F User Manual

TECHNICAL & CONSUMER INFORMATION
-32-
10. Specifications
Model G120F G160F(D) G200F(D) G160F(D)-B G200F(D)-B G160F(D)-C G200F(D)-C
Type
Single cylinder, 4-Stroke, Forced Air Cooling, OHV
Rated
power(kW/3600rpm)
2.6 3.6 4.1 3.6 3.6
Max. torque(N·m/rpm)
7.3 /
2500
10.3/
2500
12.4/
2500
Fuel
consumption(g/kW·h)
≤395
Idle speed 1800±150
SpeedFluctuating Ratio ≤10%
Transmission Mode - - -
Clutch Mode Chain mode
Reduction Ratio - - - 2:1
Noise(≤) 70db(A)
Bore×Stroke(mm) 60×42 68×45 68×54 68×45 68×54 68×45 68×54
Displacement(cc) 118 163 196 163 196 163 196
Compression Ratio 8.5:1
Lubricating mode
Splash
Starting Mode
Recoil start( Recoil start / Electric starting)
Rotation
Anti-clockwise(from P.T.O. side)
Valve Clearance
input valve：0.10 mm ~0.15mm, output valve：0.15 mm ~0.20mm
Spark plug clearance
0.7 mm ~0.8mm
Igniting Mode
Transistorized magneto Ignition
Air cleaner
Semi-dry, Oil bath, Foam filter
Dimension(Length)
(mm)
305 312 312 391 391 342 342
Dimension(Width)
(mm)
341 362 376 362 376 362 376
Dimension(High)
(mm)
318 335 335 335 335 335 335
Net weight(kg)
13 15(18) 16(19) 19(22) 20(23) 15.5(18.5) 16.5(19.5)
4.1 4.1
10.3/
2500
12.4/
2500
10.3/
2500
12.4/
2500

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
