LONCIN G200F User Manual

OPTIONAL PARTS
-37-
12. OPTIONAL PARTS
BATTERY
Use a battery rated at 12V, 18Ah or more.
Do not reverse polarity. Serious damage
to the engine and/or battery may occur.
A battery can explode if you do not follow the correct procedure,
seriously injuring anyone nearby.
Keep all sparks, open flames, and smoking materials away from the battery.
Check the electrolyte level to be sure that it is between the marks on the case. If the level
is below the lower mark, remove the caps and add distilled water to bring the electrolyte
level to the upper mark. The cells should be equally full.
LOWER LEVEL
UPPER LEVEL

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
