LONCIN G200F User Manual

TECHNICAL & CONSUMER INFORMATION
-31-
or high-temperature operation, or use in unusually wet or dusty conditions, will require
more frequent service.
Engine Tune-up
ITEM SPECIFICATION
Spark plug gap
0.028-0.031 in
(0.70 mm -0.80 mm)
Valve clearance
IN: 0.15 mm±0.02 mm (cold)
EX: 0.20 mm±0.02 mm (cold)
Other specifications No other adjustments needed
CONSUMER INFORMATION
Publications
These publications will give you additional information for maintaining and repairing your
engine. You may order them from your engine dealer.
Parts Catalog
This manual provides complete, illustrated parts lists.
QUICK REFERENCE INFORMATION
Type SAE 10W-30,API SE or SF, for general use
Engine Oil
Capacity
G120F: 0.6 L G160/G200F(D):0.6 L
G240/G270F(D):1.1L
G340/G390/G420F(D):1.1 L
Type F7RTC or other equivalents.
Spark Plug
Gap 0.028－0.031 in (0.70 mm－0.80 mm)
Carburetor Idle speed 1800 rpm±150 rpm
Each use Check engine oil. Check air filter.
First 20 hours Change engine oil.
Maintenance
Subsequent Refer to the maintenance

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
