12
DC Circuit Protector
The DC circuit protector(rated current: 10 A) automatically shuts off the DC battery
charging circuit when the DC circuit is overloaded, when there is a problem with the
battery, or the connections between the battery and the generator are improper.
The indicator inside the DC circuit protector button will pop out to show that the DC
circuit protector has switched off. Wait a few minutes and push the button in to reset the
DC circuit protector.
Connecting the battery cables:
○
1
. Before connecting charging cables to a battery that is installed in a vehicle,
disconnect the vehicle’s grounded battery cable.
The battery gives off explosive gases; keep spark, flames
and cigarettes away. Provide adequate ventilation when
charging or using batteries.
○
2
. Connect the positive (+) battery cable to the battery positive (+) terminal.
○
3
. Connect the other end of the positive (+) battery cable to the generator
○
4
. Connect the negative (-) battery cable to the battery negative (-) terminal.
○
5
. Connect the other end of the negative (-) battery cable to the generator
○
6
. Start the generator.
Do not start the vehicle while the battery charging cables are
connected and the generator is running. The vehicle or the
generator may be damaged.
An overloaded DC circuit, excessive current draw by the battery, or a wiring problem
will trip the DC circuit protector (PUSH button extends out). If this happens, wait a few
minutes before pushing in the circuit protector to resume operation. If the circuit
protector continues to go OFF, discontinue charging and see your authorized generator
dealer.
Disconnecting the battery cables:
○
1
. Stop the engine,
