35
12.OPTIONAL PARTS
I．BATTERY（battery frame inside）
Use a battery rated at 12V, 28AH or more.
Do not reverse polarity. Serious
damage to the generator and/or battery
may occur.
A battery can explode if you do not
follow the correct procedure,
seriously injuring anyone nearby.
Keep all sparks, open flames, and smoking materials away from the battery.
Check the electrolyte level to be sure that it is between the marks on the case. If the level
is below the lower mark, remove the caps and add distilled water to bring the electrolyte
level to the upper mark. The cells should be equally full.
Battery Tray Kit
○
1
. Install the battery guard on the frame.
Set the battery tray on the battery guard and tighten the bolts.
○
2
. Route the starter cable under the tank and connect it to the starter solenoid.
○
3
. Connect the ground cable to the generator rear housing.
○
4
. Set the battery on the battery tray and secure with the battery bracket.
Connect the starter cable to the battery positive (+) terminal first, then connect the
ground cable to the negative (-) terminal. When disconnecting, disconnect at the
battery negative (-) terminal first.
○
5
. Install the battery guard plate on the battery guard.
To Next Page
