7
3.CONTROLS
1) Engine Switch
To start and stop the engine.
Switch position:
○
1
To stop the engine.(OFF)
○
2
To run the engine.(ON)
○
3
Starting circuit is switched on, The starter motor starts.
To electric starter (option kit), include the START position.
2) Recoil Starter
To start the engine, pull the starter grip lightly until resistance is felt, then pull briskly.
Do not allow the starter to snap back against the engine.
Return it gently to prevent damage to the starter.
3) Fuel Valve
The fuel valve is located between the fuel tank and carburetor. When the valve lever is
in the ON position, fuel is allowed to flow from the fuel tank to the carburetor. Be sure to
return the lever to OFF after stopping the engine.
ENGINE SWITCH
OFF
ON
ENGINE SWITCH
OFF
ON
STARTER GRIP
