21
5) Fuel Sediment Cup Cleaning
The sediment cup prevents dirt or water which
may be in the fuel tank from entering the
carburetor. If the engine has not been run for a
long time, the sediment cup should be cleaned.
○
1
. Turn the fuel valve to the OFF position.
Remove the sediment cup, and o-ring.
○
2
. Clean the sediment cup, and o-ring, in
nonflammable or high flash point solvent.
○
3
. Reinstall o-ring, and sediment cup.
○
4
. Turn the fuel valve ON and check for leaks.
6) Spark Plug Service
Recommended spark plugs: F7RTC or other equivalents.
To ensure proper engine operation, the spark plug must be properly gapped and free of
deposits.
If the engine has been running, the muffler will be very hot. Be careful not to touch the
muffler.
○
1
. Remove the spark plug cap.
○
2
. Clean any dirt from around the spark plug base.
○
3
. Use the wrench supplied in the tool kit to remove the spark plug.
FUEL VALVE
SEDIMENT CUP
FUELFILTER
O-RING
SEDIMENT CUP
PLUG WRENCH
PLUG CAP
