160 SX/200SX AC/DC TIG STICK WELDER
- 9 -
Specifications and Ratings
model
parameter
TIGWELD 160SX
TIGWELD 200SX
Power voltage
1phase110V±15
%
1phase220V
±15%
1phase110V±
15%
1phase220V±
15%
Frequency (Hz)
50/60
50/60
Rated input current (A)
TIG: 37.4
TIG: 20.4
TIG: 37.4
TIG: 28
STICK: 55.8
STICK: 32.9
STICK: 58.2
STICK: 42.2
Output current regulation
(A)
TIG: 10~150
TIG: 10~160
TIG: 10~150
TIG: 10~200
STICK: 30~140
STICK: 30~160
STICK: 30~145
STICK: 30~195
No-load voltage (V)
50~80
50~80
Rated working voltage (V)
TIG: 16
TIG: 16.4
TIG: 16
TIG: 18
STICK: 25.6
STICK: 26.4
STICK: 25.8
STICK: 27.8
Pre gas time（Seconds）
0-1
0-1
Duty cycle（%）
60% @ 160 amps @ 220v
60% @ 200amps @ 220V
Post gas time（Seconds）
2-10
2-10
Foot Pedal
Yes
Yes
Arc Ignition Mode
High Frequency
High Frequency
Efficiency（%）
80
80
Load duration factor（%）
60
60
Power factor
0.73
0.73
Class of insulation
F
F
IP code
IP21
IP21
Weight（kg）
28.5
30.7
Overall dimension（mm）
705×300×565
705×300×565
Max welding thickness
（mm）
8
10
