160 SX/200SX AC/DC TIG STICK WELDER
- 10 -
SETUP:
Description of the panel function
Figure for TIGWELD 200SX panel
1.Current adjusting knob
2. Cleaning pulse width adjustment knob
3. Current meter
4. ARC/TIG change-over switch
5. HF/Life ARC change-over switch
6. Last flow time adjustment
7. Pre-flow time adjustment
8. Power switch
9. Pulse frequency change-over switch
10. AC/DC change-over switch
11. TIG welding torch interface
12. STICK welding interface
13. TIG welding torch switch/
Remote control socket
14. Ground clamp interface
