SETUP &
USE
When setting the camera up downrange, there are two critical steps
to ensure the optimal experience.
The camera is designed to be in focus when set up 10-20 ft.
from the target. Depending on the size of your target and your
desired field of view, you will need to move the camera within
this range until you are satisfied with the field of view. It is
recommended that you get the camera as close as possible
while still maintaining a full view of the target and keeping the
image in focus.
CAMERA SETUP
6 to 24 ft
Determine the appropriate distance from the target:
1.
DISTANCE BETWEEN
TARGET AND CAMERA
Page 4
CAMERA FIELD OF VIEW CHART (W x H)
Distance
from Target
6’ 22” x 13”
30” x 17”
37” x 21”
46” x 24”
53” x 31”
60” x 35”
68” x 40”
77” x 45”
84” x 48”
91” x 53”
8’
10’
12’
14’
16’
18’
20’
22’
24’
FOV
Distance
from Target
FOV
