IMPORTANT NOTE:
• Place all laminated parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
• Check to be sure that you have all parts and hardware.
• Remove all wrapping materials, including staples and packing straps before you start to assemble.
• Don’t tighten all screws/bolts until all completely assembled.
• Keep all hardware parts out of reach of children.
• It is recommended for 2 persons to complete this assembly.
Two people are required to
assemble and move this model.
STEP 1
STEP 3
STEP 2
STEP 4
M4.8 x 22
16 Pcs
+ 1 extra Pc
M8 x 10
4 Pcs
+ 1 extra Pc
M6 x 12
10 Pcs
+ 1 extra Pc 3 Pcs
M5 x 16
3 Pcs
+ 1 extra Pc
4mm
1 Pc
M6 x 25
8 Pcs
+ 1 extra Pc
M4 x 13
3 Pcs
M8x10
Spring Washer
4 Pcs
+ 1 extra Pc
M6x25
Spring Washer
8 Pcs
+ 1 extra Pc
A EB FC GD H I J
Assemble bracket and two legs with 4pcs "E"
screws and 4pcs "I" spring washers (do not tighten).
Carefully remove frame
Open two legs (see picture).
Assembly Instructions
Assemble 2pcs "C" screws on one side. Do not tighten.
Then assemble 2 pcs "C" screws on the other side.
(Do not tighten).
Pay attention to the direction of the legs.
60" Pneumatic
Height Adjustable Desk
99551/59605/59606/59634/59635/59636/16202/59611/59612
E X 4
I X 4
E
F
I
C
F
C X 4
D
X 8
J
X 8
F
D
J
To Next Page
