DIGITAL VIDEO SURVEILLANCE RECORDER
Specifications
SYSTEM
Operating System Linux (embedded)
Pentaplex Simultaneous View, Record, Playback, Backup & Remote Monitoring
Number of Channels 8/16 Channel
Inputs/Outputs
Video IN 8/16 x 1Vp-p, CVBS, 75ohms, BNC
Video OUT 8/16 1 x BNC
VGA OUT Yes
HDMI Yes. Video and Audio
Audio IN 8 line IN (RCA), G.711(8 ch), 4 line in(RCA), G.711(16 ch)
Audio OUT 1 line OUT (RCA), G.711
USB Port 1 at the back, 1 at the front
Alarm IN 8 ch IN
Alarm OUT 1 ch OUT
Video Output Resolution 800x600, 1024x768, 1280x1024, 1440x900, HDMI
(1920x1080)
PTZ control RS-485 Pelco D & P Protocol
Display
Live Display 8 ch: 1, 4, 8
16 ch: 1, 4, 9, 16
Live Display Speed 240fps (8 ch)/ 480 fps (16 ch) NTSC
200fps (8 ch)/ 400fps (16 ch) PAL
OSD ON/OFF
System Navigation USB Mouse, IR Remote Controller, Front Panel
Motion Area Setting Adjustable grid (30x44) NTSC
Adjustable grid (36x44) PAL
Sensitivity levels 8
Firmware Upgrade Automatic over the Internet & via USB device and Network
User Authority By user group
Time Synchronization Auto time sync by NTP server
RECORDING
Video Compression H.264
Audio Compression G.711
Recording Resolution NTSC:
960H: 960x480, 960x240, 480x240
D1 mode: 720x480(D1), 720x240(2CIF), 360x240(CIF)
PAL:
960H: 960x576, 960x288, 480x288
D1 mode: 720x576(D1), 720x288(2CIF), 360x288(CIF)
Recording Speed NTSC:
8ch: 960H: 240fps @ 960x480, 960x240 & 480x240
D1 mode: 240fps @ D1, 2CIF & CIF
PAL:
960H: 200fps @ 960x576, 960x288 & 480x288
D1 mode: 200fps @ D1, 2CIF & CIF
Recording Speed NTSC:
16ch: 960H: 480fps @ 480x240,160fps @ 960x480 & 960x240
D1 mode: 480fps @ CIF, 224 fps @ D1 & 2CIF
PAL:
960H: 400fps @ 480x288,144fps @ 960x576 & 960x288
D1 mode: 400fps @ CIF, 192fps @ D1 & 2CIF
Recording Resolution Setting Per camera for different resolutions
Recording Quality Control 3 levels
Recording Schedule By hour, by day, by recording mode, by motion, by
alarm, by ch
Pre Recording Max. 10 Secs
Post Recording Max. 5 Minutes
Reliability Watch-Dog, Auto-recovery after power failure
Covert Video Yes
PLAYBACK
Playback Channel 1~8 Adjustable (8 ch), 1~16 Adjustable (16 ch)
Playback Speed Variable Max 16x
Playback Players Backup Player
Search By time & event
Log Search Up to 10,000 lines for alarm activated, motion
detected, configuration changes, connects/disconnects
and video loss.
Audio Play Yes
STORAGE & ARCHIVE
Storage 8 ch: Up to 1 HDD’s (SATA)
16 ch: Up to 2 HDD’s (SATA)
Maximum Capacity 8 ch: up to 1x 2TB
16 ch: up to 2x 2TB
Backup Media USB Flash Drive & HDD
Backup File Format H.264 file (AVI generator included)
CONNECTIVITY
Cloud Connection Lorex Stratus Connectivity
Supported Operating Systems Windows™ 7
, 8
Mac OSX Snow Leopard 10.6 or above
Remote Software Client Software (PC) & Safari 6.0 (Mac)
Email notification Text with snapshot
Instant Smart Phone Compatibility† Smart Phone & Tablet Compatibility: iPad
®
,
iPhone
®
, Android (version 2.3 & above)
DDNS Free Lorex DDNS
System Configuration Full setup configuration over network
Ports Programmable by User
Network Protocol TCP/IP / DHCP / UDP / DDNS / PPPoE
Network Interface 10/100-Base-TX, RJ-45
Network Speed Control 48Kb ~ 8MB/sec.
GENERAL
Power Consumption Approx. 10 watts (no HDD included)
Supply Voltage 8 ch: 100VAC-240VAC, 12VDC , 2A, 50/60Hz
16 ch: 100VAC-240VAC, 12VDC , 5A, 50/60Hz
Unit Dimensions 8 ch:11.8”/300mm x 9.9”/251mm x
(W x D x H) 2.4”/60mm
16 ch:14.9” /340mm x13.3”/340mm x
1.9”/50mm
Unit Weight (KGs) 8 ch: 1.7 kg/3.75 Lbs
16 ch: 3 kg/6.6 Lbs
Operating temperature 32° ~ 104° F / 0° ~ 40° C
Humidity 10 ~ 90% NC
DVR:
RECORDING RESOLUTION (PIXELS) & SPEED (FPS - FRAMES PER SECOND)
FPS
960H Mode D1 Mode
960H ½ 960H ¼ 960H D1 ½ D1 ¼ D1 (CIF)
960 x 480 960 x 240 480 x 240 720 x 480 720 x 240 360 x 240
8ch
Total
240 240 240 240 240 240
Per channel
30 30 30 30 30 30
16ch
Total
160 160 480 224 224 480
Per channel
10 10 30 14 14 30
