PARTS LIST
Part No. Description
A 001-005 Top Cover
B 001-006 Base
C 001-007 Drive Shaft
D 001-008 Idler Shaft
E 203-004 Bearing, Open End (1 Required)
F 203-003 Bearing, Closed End (3 Required)
G 001-101 Drive Pulley Assembly
H 001-100 Motor Pulley With Fan
I 206-012 Retaining Ring
J 210-001 Drive Belt
K 301-034 Motor, 110v
K 301-035 Motor, 220v
L 350-003 Cord, EU, 220v
L 350-004 Cord, UK, 220v
L 350-005 Cord, USA, 110v
L 350-010 Cord, Aus/NZ, 220v
M 320-001 Strain Relief, 110v
M 320-002 Strain Relief, 220v
Part No. Description
020-091 Complete Rubber Barrel Assembly
N 020-100 Inner Lid
O 020-001 Outer Lid
P 481-070 Knurled Nut
Q 240-010 Boot Gasket
R 240-002 Rubber Barrel Only
S 108-001 Barrel Washer
