BULB REPLACEMENT
Headlamp Bulb
Mounted in the front body are the two headlamp units, each
of which houses a halogen projector type low beam lamp
(upper), and a halogen high beam lamp (lower) including the
sidelamp bulb.
For access to the headlamp bulbs, first remove the clear cover
and mask from the body (see previous pages).
WARNING:
• Allow bulbs to cool before attempting removal, or your
fingers could be burnt.
• Halogen bulbs have pressurised gas inside and can burst
if you drop or scratch the bulb. You or others could be
injured.
• Be sure to read and follow instructions on the bulb
packaging.
NOTICE: Do not touch a halogen bulb glass envelope with the
fingers, as the greasy deposit left behind will greatly reduce bulb
life. Use a paper tissue to handle the bulb.
Low beam bulb: Disconnect the single cable, release the spring
wire clip, and withdraw the 55W H1 bulb. On refitting, note that
the bulb is keyed to allow only one orientation.
ohs107
Low beam lamp
High beam lamp
Parking lamp bulb
Electrical
