Doc: I414EGB03_16.doc 02/12/2014 p. 21 / 33
Tabla de alarmas
CÓD. Descripción
Habilitado
Solo AUT
Retenido
Al. gen.
Bloqueo de BRK1
Bloqueo de BRK2
Sirena
Inhibición
Sin LCD
A01 Tensión de la batería demasiado baja
A02 Tensión de la batería demasiado alta
A03 Tiempo límite de interruptor de línea 1
A04 Tiempo límite de interruptor de línea 2
A05 Error de secuencia de fase de línea 1
A06 Error de secuencia de fase de línea 2
A07 Tiempo límite sin suministro carga
A08 Avería del cargabaterías externo
A09 Emergencia
A10
Intervención de protección
Interruptor de línea 1 (trip)
A11
Intervención de protección
Interruptor de línea 2 (trip)
A12 Generador de línea 1 no disponible
A13 Generador de línea 2 no disponible
A14 Mantenimiento en horas 1
A15 Mantenimiento en horas 2
A16 Mantenimiento en maniobras 1
A17 Mantenimiento en maniobras 2
A18 Alarma de tensión auxiliar
A
larm table
COD
DESCRIPTION
Enabled
Only AUT
Retained
Glob. Al.
Lock BRK1
Lock BRK2
Siren
Inhibit.
No LCD
A01 Battery voltage too low
A02 Battery voltage too high
A03 Line 1 circuit breaker timeout
A04 Line 2 circuit breaker timeout
A05 Line 1 wrong phase sequence
A06 Line 2 wrong phase sequence
A07 Timeout load not powered
A08 External battery charger failure
A09 Emergency
A10 Line 1 breaker protection trip
A11 Line 2 breaker protection trip
A12 Line 1 generator not available
A13 Line 2 generator not available
A14 Line 1 maintenance hours elapsed
A15 Line 2 maintenance hours elapsed
A16 Line 1 Maintenance operations
A17 Line 2 Maintenance operations
A18 Auxiliary voltage failure
Descripción de las alarmas
C
Ó
D. DESCRIPCI
Ó
N CAUSA DE LA ALARMA
A01
Tensión de la
batería demasiado
ba
j
a
Tensión de la batería por debajo del umbral mínimo durante un
tiempo superior al configurado.
A02
Tensión de la batería
demasiado alta
Tensión de la batería por encima del umbral máximo durante
un tiempo superior al configurado.
A03
Tiempo límite de
interruptor de línea 1
El dispositivo de conmutación de la L
Í
NEA 1 no ha realizado la
maniobra de apertura o cierre en el tiempo máximo
configurado. Una vez que se genera la alarma, el comando de
apertura o cierre se inhibe. Las alarmas se generan solamente
cuando al menos una de las dos fuentes de alimentación está
conectada (valor por encima de los umbrales mínimos
p
ro
g
ramados
)
.
A04
Tiempo límite de
interruptor de línea 2
El dispositivo de conmutación de la L
Í
NEA 2 no ha realizado la
maniobra de apertura o cierre en el tiempo máximo
configurado. Una vez que se genera la alarma, el comando de
apertura o cierre se inhibe. Las alarmas se generan solamente
cuando al menos una de las dos fuentes de alimentación está
conectada (valor por encima de los umbrales mínimos
programados).
A05
Error de secuencia
de fase de línea 1
La secuencia de fase detectada en la L
Í
NEA 1 no se
corresponde con la programada.
A06
Error de secuencia
de fase de línea 2
La secuencia de fase detectada en la L
Í
NEA 2 no se
corresponde con la programada.
A07
Tiempo límite sin
suministro carga
La carga ha permanecido sin alimentación durante más tiempo
del programado con P05.11 debido a que las líneas de
alimentación no estaban disponibles o a que ambos
interruptores han quedado abiertos.
A08
Avería del
cargabaterías
externo
A
larma que genera la entrada programada con la función
Alarma de cargabaterías conectada a un cargabaterías
externo cuando al menos una de las fuentes de alimentación
está dentro de los límites.
A09 Emergencia
A
larma que genera la apertura de la entrada externa de
emergencia. Se abren ambos interruptores.
A10
Intervención de
protección
Interruptor de línea 1
(trip)
El interruptor de la línea 1 se ha abierto debido a la
intervención de protección contra sobreintensidad, que indica
la entrada correspondiente con la función Intervención de
protección de interruptor de línea 1.
A11
Intervención de
protección
Interruptor de línea 2
(trip)
El interruptor de la línea 2 se ha abierto debido a la
intervención de protección contra sobreintensidad, que indica
la entrada correspondiente con la función Intervención de
protección de interruptor de línea 2.
A12
Generador de línea
1 no disponible
A
larma que genera la entrada Generador de línea 1
preparado.
A13
Generador de línea
2 no disponible
A
larma que genera la entrada Generador de línea 2
preparado.
A14
Mantenimiento en
horas 1
Se genera cuando el número de horas de mantenimiento
correspondiente a la LÍNEA 1 llega a cero. Consultar el menú
M12. Utilizar el menú de comandos para restablecer las horas
de funcionamiento y borrar la alarma.
A15
Mantenimiento en
horas 2
Se genera cuando el número de horas de mantenimiento
correspondiente a la LÍNEA 2 llega a cero. Consultar el menú
M12. Utilizar el menú de comandos para restablecer las horas
de funcionamiento y borrar la alarma.
A
larm description
COD DESCRIPTION ALARM EXPLANATION
A01
Battery voltage too
low
Battery voltage beyond the lowest threshold for a time
exceeding the time set.
A02
Battery voltage too
high
Battery voltage beyond the highest threshold for a time
exceeding the time set.
A03
Line 1 circuit
breaker timeout
The LINE 1 changeover device did not perform the opening or
closing operation within the max. time set. After alarm
generation, the opening or closing command is inhibited.
Alarms are generated only if at least one of the two power
sources is present, i.e. if it is higher that the minimum
thresholds programmed.
A04
Line 2 circuit
breaker timeout
The LINE 2 changeover device did not perform the opening or
closing operation within the max. time set. After alarm
generation, the opening or closing command is inhibited.
Alarms are generated only if at least one of the two
power sources is present, i.e. if it is higher that the
minimum thresholds programmed.
A05
Line 1 wrong phase
sequence
The phase sequence recorded on LINE 1 does not correspond
to the one programmed.
A06
Line 2 wrong phase
sequence
The phase sequence recorded on LINE 2 does not correspond
to the one programmed.
A07
Load not powered
timeout
The load has been without power for a time longer than the
maximum specified with P05.11, either because both source
lines were absent or because both the breakers remained
open.
A08
External battery
charger failure
Alarm generated by an input with the function Battery charger
alarm, while at least one of the source lines source is in the
correct limits.
A09 Emergency
Alarm generated by the opening of the external input with
Emergency function. Both breakers will be opened.
A10
Line 1 breaker
protection trip
Line 1 breaker has tripped because of an overcurrent
protection, signalled by activation of the input with function
Line 1 breaker protection trip.
A11
Line 2 breaker
protection trip
Line 2 breaker has tripped because of an overcurrent
protection, signalled by activation of the input with function
Line 2 breaker protection trip.
A12
Line 1 generator not
available
Alarm generated by the input Generator Line 1 ready.
A13
Line 2 generator not
available
Alarm generated by the input Generator Line 2 ready.
A14
Maintenance hours
line 1
Alarm generated when the maintenance hours for LINE 1
arrive to zero. See M12 menu. Use the command menu to
restore the working hours and reset the alarm.
A15
Maintenance hours
line 2
Alarm generated when the maintenance hours for LINE 2
arrive to zero. See M12 menu. Use the command menu to
restore the working hours and reset the alarm.
