Page #14 background image
I581 GB I 05 18 31100420
14
G
B
Site altitude
0 … 1000 m a.m.s.l.
1000 … 4000 m a.m.s.l. Reduce rated output current by 5 %/1000 m
Pollution
Degree of pollution 2 EN 61800-5-1
Vibration resistance
Transport
2M2 (sine, shock) EN 60721-3-2
Operation
Amplitude 1 mm Germanischer Lloyd 5 ... 13.2 Hz
Acceleration resistant up to 0.7 g 13.2 ... 100 Hz
Amplitude 0.075 mm EN 61800-5-1 10 ... 57 Hz
Acceleration resistant up to 1 g 57 ... 150 Hz
Noise emission
Category C2 EN 61800-3 Type-dependent, for motor cable lengths see rated data
Noise immunity
Meets requirement in compliance with EN 61800-3
5.2 TECHNICAL DATA
The output currents apply to these operating conditions:
At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45°C.
At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Power kW 0.25 0.4 0.75 1.5 2.2
Mains voltage range 1/N/PE AC 170 V ... 264 V, 45 Hz ... 65 Hz
Rated mains current
without mains choke A 4 5.7 10 16.7 22.5
with mains choke A 3.6 4.8 8.8 13.9 16.9
Output current
2 kHz A - - 4.2 7 9.6
4 kHz A 1.7 2.4 4.2 7 9.6
8 kHz A 1.7 2.4 4.2 7 9.6
16 kHz A 1.1 1.6 2.8 4.7 6.4
Power loss W 15 20 33 50 70
Overcurrent cycle 180 s
Max. output current A 2.55 3.6 6.3 10.5 14.4
Overload time s 60 60 60 60 60
Recovery time s 120 120 120 120 120
Max. output current during the recovery time A 1.28 1.8 3.15 5.25 7.2
Overcurrent cycle 15 s
Max. output current A 3.4 4.8 8.4 14 19.2
Overload time s 3 3 3 3 3
Recovery time s 12 12 12 12 12
Max. output current during the recovery time A 1.28 1.8 3.15 5.25 7.2
Motor cable length
shielded, without EMC m 50
C2 residential area / industrial premises m
5
20
Weight kg 0.75 0.95 1.35
