LOVATO ELECTRIC VLA1 series Installation Manual

I581 GB I 05 18 31100420
9
G
B
3.3.1.1 FUSING AND TERMINAL DATA
Power kW 0.25 0.4 0.75 1.5 2.2
Cable installation in compliance with EN 60204-1
Laying system B2
Operation without mains choke
Fuse
Characteristic gG/gL or gRL
Max. rated current A 10 10 16 25 25
Circuit breaker
Characteristic B
Max. rated current A 10 10 16 25 25
Operation with mains choke
Fuse
Characteristic gG/gL or gRL
Max. rated current A 10 10 16 25 25
Circuit breaker
Characteristic B
Max. rated current A 10 10 16 25 25
Earth-leakage circuit breaker ≥ 30 mA, type A or B
Mains connection
Connection X100
Connection type Screw terminal
Min. cable cross-section mm² 1
Max. cable cross-section mm² 2.5 6
Stripping length mm 8
Tightening torque Nm 0.5 0.7
Required tool 0.5 x 3.0 0.6 x 3.5
Motor connection
Connection X105
Connection type Screw terminal
Min. cable cross-section mm² 1
Max. cable cross-section mm² 2.5
Stripping length mm 8
Tightening torque Nm 0.5
Required tool 0.5 x 3.0
PE connection
Connection PE
Connection type PE screw
Min. cable cross-section mm² 1
Max. cable cross-section mm² 6
Stripping length mm 10
Tightening torque Nm 1.2
Required tool 0.8 x 5.5
