1 SAFETY INFORMATION
1.1 Basic safety measures
Disregarding the following basic safety measures may lead to severe personal injury and damage to material assets!
The product
– must only be used as directed.
– must never be commissioned if they display signs of damage.
– must never be technically modified.
– must never be commissioned if they are not fully mounted.
– must never be operated without required covers.
Connect/disconnect all pluggable terminals only in deenergised condition. Only remove the product from the installation in the deenergised state.
Insulation resistance tests between 24V control potential and PE: According to EN 61800−5−1, the maximum test voltage must not exceed 110 V DC.
Observe all specifications of the corresponding documentation supplied. This is the precondition for safe and trouble-free operation and for obtaining the product features specified.
The procedural notes and circuit details described in this document are only proposals. It is up to the user to check whether they can be adapted to the particular applications. LOVATO Electric does
not take any responsibility for the suitability of the procedures and circuit proposals described.
The product must only be used by qualified personnel. IEC 60364 define the skills of these persons:
– They are familiar with installing, mounting, commissioning, and operating the product.
– They have the corresponding qualifications for their work.
– They know and can apply all regulations for the prevention of accidents, directives, and laws applicable at the place of use.
Observe the specific notes in the other chapters!
1.2 Residual hazards
The user must take the residual hazards mentioned into consideration in the risk assessment for his/her machine/system.
If the above is disregarded, this can lead to severe injuries to persons and damage to material assets!
PRODUCT
Observe the warning labels on the product!
ICON DESCRIPTION
Electrostatic sensitive devices
Before working on the drive, the staff must ensure to be free of electrostatic charge!
Dangerous electrical voltage
Before working on the drive, check whether all power connections are dead! After mains OFF, power connections X100 and X105 carry a dangerous electrical
voltage for the time specified on the drive!
High leakage current
Carry out fixed installation and PE connection in compliance with EN 61800-5-1 or EN 60204-1!
Hot surface
Use personal protective equipment or wait until devices have cooled down!
MOTOR
If there is a short circuit of two power transistors, a residual movement of up to 180°/number of pole pairs can occur at the motor! (For 4-pole motor: residual movement max. 180°/2 = 90°).
This residual movement must be taken into consideration by the user for his/her risk assessment.
1.3 Application as directed
– The product must only be operated under the operating conditions prescribed in this documentation.
– The product meets the protection requirements of 2014/35/EU: Low-Voltage Directive.
– The product is not a machine in terms of 2006/42/EC: Machinery Directive.
– Commissioning or starting the operation as directed of a machine with the product is not permitted until it has been ensured that the machine meets the regulations of the EC Directive
2006/42/EC: Machinery Directive; observe EN 60204−1.
– Commissioning or starting the operation as directed is only allowed when there is compliance with the EMC Directive 2014/30/EU.
– The harmonised standard EN 61800−5−1 is used for the drives.
– The product is not a household appliance, but is only designed as component for commercial or profes- sional use in terms of EN 61000−3−2.
– In accordance with EN 61800−3, the product can be used in drive systems that have to comply with the categories given in the technical data.
In residential areas, the product may cause EMC interferences. The operator is responsible for taking interference suppression measures.
