Lovato DMG 700 - Page 11

Doc. I317IGB12_19.doc 18/12/2019 P. 11 / 41
Indirizzo
Address
WORDS
MISURA
MEASURE
UNITA’
UNIT
FORMATO
FORMAT
DMG
110
210
DMG
300
DMG
700
DMG
800
DMG
900
DMG
6...
MISURA MASSIMA (HI) MAXIMUM MEASURE (HI)
0400H 2 Tensione di fase L1 L1 Phase Voltage V/100 Unsigned long
● ● ● ● ● ●
0402H 2 Tensione di fase L2 L2 Phase Voltage V/100 Unsigned long
● ● ● ● ● ●
……..
0462H 2 Thd Tensione L3-1 Thd L3-1 Voltage %/100 Unsigned long
● ● ● ● ● ●
MISURA MINIMA (LO) MINIMUM MEASURE (LO)
0600H 2 Tensione di fase L1 L1 Phase Voltage V/100 Unsigned long
● ● ● ● ● ●
0602H 2 Tensione di fase L2 L2 Phase Voltage V/100 Unsigned long
● ● ● ● ● ●
……..
0662H 2 Thd Tensione L3-1 Thd L3-1 Voltage %/100 Unsigned long ● ● ● ● ● ●
MISURA MEDIA (AV) AVARAGE MEASURE (AV)
0800H 2 Tensione di fase L1 L1 Phase Voltage V/100 Unsigned long
● ● ● ● ● ●
0802H 2 Tensione di fase L2 L2 Phase Voltage V/100 Unsigned long
● ● ● ● ● ●
……..
0862H 2 Thd Tensione L3-1 Thd L3-1 Voltage %/100 Unsigned long ● ● ● ● ● ●
MISURA MAX DEMAND (MD) MAX DEMAND MEASURE (MD)
0A00H 2 Tensione di fase L1 L1 Phase Voltage V/100 Unsigned long
● ● ● ● ● ●
0A02H 2 Tensione di fase L2 L2 Phase Voltage V/100 Unsigned long
● ● ● ● ● ●
……..
0A62H 2 Thd Tensione L3-1 Thd L3-1 Voltage %/100 Unsigned long ● ● ● ● ●
ARMONICHE HARMONICS
3100H
1
2. Armonica Tensione L1 2. Harmonic L1 Voltage %/10 Unsigned int
●
3101H
1
3. Armonica Tensione L1 3. Harmonic L1 Voltage %/10 Unsigned int
●
………..
313FH
1
63. Armonica Tensione L1 63. Harmonic L1 Voltage %/10 Unsigned int
●
3140H
1
2. Armonica Tensione L2 2. Harmonic L2 Voltage %/10 Unsigned int
●
………..
317FH
1
63. Armonica Tensione L2 63. Harmonic L2 Voltage %/10 Unsigned int
●
3180H
1
2. Armonica Tensione L3 2. Harmonic L3 Voltage %/10 Unsigned int
●
………..
31BFH
1
63. Armonica Tensione L3 63. Harmonic L3 Voltage %/10 Unsigned int
●
3340H
1
2. Armonica Tensione N 2. Harmonic N Voltage %/10 Unsigned int
●
………..
337FH
1
63. Armonica Tensione N 63. Harmonic N Voltage %/10 Unsigned int
●
31C0H
1
2. Armonica Corrente L1 2. Harmonic L1 Current %/10 Unsigned int
●
………..
31FFH
1
63. Armonica Corrente L1 31. Harmonic L1 Current %/10 Unsigned int
●
3200H
1
2. Armonica Corrente L2 2. Harmonic L2 Current %/10 Unsigned int
●
………..
323FH
1
63. Armonica Corrente L2 63. Harmonic L2 Current %/10 Unsigned int
●
3240H
1
2. Armonica Corrente L3 2. Harmonic L3 Current %/10 Unsigned int
●
………..
327FH
1
63. Armonica Corrente L3 63. Harmonic L3 Current %/10 Unsigned int
●
3380H
1
2. Armonica Corrente N 2. Harmonic N Current %/10 Unsigned int
●
………..
33BFH
1
63. Armonica Corrente N 63. Harmonic N Current %/10 Unsigned int
●
3280H
1
2. Armonica Tensione L1-L2 2. Harmonic L1-L2 Voltage %/10 Unsigned int
●
………..
32BFH
1
63. Armonica Tensione L1-L2 63. Harmonic L1-L2 Voltage %/10 Unsigned int
●
32C0H
1
2. Armonica Tensione L2-L3 2. Harmonic L2-L3Voltage %/10 Unsigned int
●
………..
32FFH
1
63. Armonica Tensione L2-L3 63. Harmonic L2-L3Voltage %/10 Unsigned int
●
3300H
1
2. Armonica Tensione L3-L1 2. Harmonic L3-L1Voltage %/10 Unsigned int
●
………..
333FH
1
63. Armonica Tensione L3-L1 63. Harmonic L3-L1Voltage %/10 Unsigned int
●
