Doc. I317IGB12_19.doc 18/12/2019 P. 22 / 41
TABELLA 8: TABLE 8:
PARAMETRI SETUP SETUP PARAMETERS
(Utilizzabili con funzioni 04 e 06) (To be used with functions 04 and 06)
CODE MENU MENU MIN MAX DEF WORDS
ADDRESS
DMG
110
210
DMG
300
DMG
700
DMG
800
DMG
900
DMG
6...
M01 Generale General
P01.01 Primario TA CT primary 1 10000 5 1 5000H
P01.02 Secondario TA CT secondary 0 1 1 1 5002H
P01.03 Tensione nominale Rated voltage 49 500000 49 2 5004H
P01.04 Utilizzo TV Use VT 0 1 0 1 5006H
P01.05 Primario TV VT primary 50 500000 100 2 5008H
P01.06 Secondario TV VT secondary 50 500 100 1 500AH
P01.07 Tipo di collegamento Wiring 0 5 0 1 500CH
M02 Utilità Utility
P02.01 Lingua Language 0 4 0 1 5080H
P02.02 Contrasto LCD Display contrast 0 50 100 1 5082H
P02.03
Intensità
retroilluminazione
display alta
High backlight level 10 100 100 1 5084H
P02.04
Intensità
retroilluminazione
display bassa
Low backlight level 10 100 30 1 5086H
P02.05
Tempo passaggio a
retroilluminazione bassa
Delay to low backl. 5 600 30 1 5088H
P02.06 Ritorno a pagina di default Default page return 9 600 60 1 508AH
P02.07
Pagina di default Default page
1 32 1 1 508CH
P02.08 Sotto-pagina di default Default sub-page 0 13 0 1 508EH
P02.09
Tempo di aggiornamento
display
Display update time 1 50 5 1 5090H
M03 Password Password
P03.01 Abilitazione password Enable passwords 0 1 0 1 5100H
P03.02 Password livello utente User level Password 0 9999 1000 1 5102H
P03.03 Password livello avanzato
A
dvanced level Password 0 9999 2000 1 5104H
M04 Integrazione Integration
P04.01 Modo integrazione Integration mode 0 3 1 1 5180H
P04.02 Tempo integ. Potenze Power integration time 1 60 15 1 5182H
P04.03 Tempo integ. Correnti Current integration time 1 60 15 1 5184H
P04.04 Tempo integ. Tensioni Voltage integration time 1 60 1 1 5186H
P04.05 Tempo integ. Frequenza Frequency integration time 1 60 1 1 5188H
M05 Contaore Hour counters
P05.01 Abil . generale contaore Hour counters enable 0 1 1 1 5200H
P05.02 Abil contaore parziale Partial hour counter enable 0 4 1 1 5202H
P05.03 Numero canale (x) Channel number (x) 1 8 1 1 5204H
M06 Grafico trend Trend graph
P06.01 Misura per pagina trend Trend graph measure 0 3 1 1 5280H
P06.02 Autorange scala Autorange 0 1 1 1 5282H
P06.03 Valore fondo scala Full scale value 0 1000 1000 1 5284H
P06.04 Moltiplicatore fondo scala Full scale multiplier 0 2 0 1 5286H
