Doc. I317IGB12_19.doc 18/12/2019 P. 23 / 41
CODE MENU MENU MIN MAX DEF WORDS ADDRESS
DMG
110
210
DMG
300
DMG
700
DMG
800
DMG
900
DMG
600
610
M07 Comunicazione Communication
P07.n.01 Indirizzo seriale nodo Serial node address 1 255 1 1 5300H + (n -1) * 80H ● ● ● ● ●
P07.n.02 Velocità seriale Serial speed 0 5 3 1
5302H + (n -1) * 80H
● ● ● ● ●
P07.n.03 Formato dati Data format 0 4 0 1
5304H + (n -1) * 80H
● ● ● ● ●
P07.n.04 Bit di stop Stop bits 0 1 0 1
5306H + (n -1) * 80H
● ● ● ● ●
P07.n.05 Protocollo Protocol 0 1 0 1
5308H + (n -1) * 80H
● ● ● ● ●
P07.n.06 Indirizzo IP IP address 0 255 0.0.0.0 2
530AH + (n -1) * 80H
● ● ● ● ●
P07.n.07 Subnet mask Subnet mask 0 255 0.0.0.0 2 530CH + (n -1) * 80H ● ● ● ● ●
P07.n.08 Porta IP IP port 0 9999 1001 1
530EH + (n -1) * 80H
● ● ● ● ●
M08 Soglie limite Limit thresholds
P08.n.01 Misura riferimento Reference measure 0 41 0 1
5400H + (n -1) * 80H
● ● ● ●
P08.n.02 Funzione Function 0 2 0 1 5402H + (n -1) * 80H ● ● ● ●
P08.n.03 Soglia superiore Upper threshold -9999 9999 0 1(signed)
5404H + (n -1) * 80H
● ● ● ●
P08.n.04 Moltiplicatore Multiplier 0 6 2 1
5406H + (n -1) * 80H
● ● ● ●
P08.n.05 Ritardo Delay 0 6000 0 1
5408H + (n -1) * 80H
● ● ● ●
P08.n.06 Soglia inferiore Lower threshold -9999 9999 0 1(signed)
540AH + (n -1) * 80H
● ● ● ●
P08.n.07 Moltiplicatore Multiplier 0 6 2 1
540CH + (n -1) * 80H
● ● ● ●
P08.n.08 Ritardo Delay 0 6000 0 1 540EH + (n -1) * 80H ● ● ● ●
P08.n .09 Stato di riposo Normal status 0 1 0 1
5410H + (n -1) * 80H
● ● ● ●
P08.n .10 Memoria Latch 0 1 0 1
5412H + (n -1) * 80H
● ● ● ●
M09 Allarmi Alarms
P09.n .01 Sorgente allarme Alarm source 0 3 0 1 5800H + (n -1) * 80H ● ● ● ●
P09.n .02 Numero canale (x) Channel number (x) 1 8 1 1
5802H + (n -1) * 80H
● ● ● ●
P09.n .03 Memoria Latch 0 1 0 1
5804H + (n -1) * 80H
● ● ● ●
P09.n .04 Priorità Priority 0 1 0 1
5806H + (n -1) * 80H
● ● ● ●
P09.n .05 Testo Text ALAn 8
5808H + (n -1) * 80H
● ● ●
M10 Contatori Counters
P10.n .01 Sorgente conteggio Counter source 0 4 0 1
5C00H + (n -1) * 80H
● ● ● ●
P10.n .02 Numero canale (x) Channel number (x) 1 8 1 1
5C02H + (n -1) * 80H
● ● ● ●
P10.n .03 Moltiplicatore Multiplier 1 1000 1 1
5C04H + (n -1) * 80H
● ● ● ●
P10.n .04 Divisore Divider 1 1000 1 1
5C06H + (n -1) * 80H
● ● ● ●
P10.n .05
Descrizione del
contatore
Counter description CNTn 8
5C08H + (n -1) * 80H
● ●
●
P10.n .06 Unità di misura Unit of measure Umn 3
5C10H + (n -1) * 80H
● ● ●
M11 Impulsi energia Energy Pulse
P11.n .01 Misura sorgente
Source
measurement
0 5 0 1
5E00H + (n -1) * 80H
● ● ● ●
P11. n.02 Unità conteggio Count unit 0 3 1 1
5E02H + (n -1) * 80H
● ● ● ●
P11. n.03 Durata impulso Pulse duration 10 1000 100 1
5E04H + (n -1) * 80H
● ● ● ●
M12 Logica booleana Boolean Logic
P12.n .01 Operando 1 Operand 1 0 5 0 1
6080H + (n -1) * 80H
● ● ● ●
P12.n .02 Numero canale (x) Channel number (x) 1 8 1 1 6082H+ (n -1) * 80H ● ● ● ●
P12.n .03 Operatore logico 1 Logic operator 1 0 6 0 1
6084H + (n -1) * 80H
● ● ● ●
P12.n .04 Operando 2 Operand 2 0 5 0 1
6086H + (n -1) * 80H
● ● ● ●
P12.n .05 Numero canale (x) Channel number (x) 1 8 1 1
6088H + (n -1) * 80H
● ● ● ●
P12.n .06 Operatore logico 2 Logic operator 2 0 6 0 1
608AH + (n -1) * 80H
● ● ● ●
P12.n .07 Operando 3 Operand 3 0 5 0 1
608CH + (n -1) * 80H
● ● ● ●
P12.n .08 Numero canale (x) Channel number (x) 1 8 1 1 608EH + (n -1) * 80H ● ● ● ●
P12.n .09 Operatore logico 3 Logic operator 3 0 6 0 1
6090H + (n -1) * 80H
● ● ● ●
P12.n .10 Operando 4 Operand 4 0 5 0 1
6092H + (n -1) * 80H
● ● ● ●
P12.n .11 Numero canale (x) Channel number (x) 1 8 1 1
6094H + (n -1) * 80H
● ● ● ●
