Nota:
Nelle tabelle il numero vicino al simbolo ‘●’ indica la rev SW del DMG a partire dalla quale l’indirizzo specificato viene supportato dal protocollo.
Note:
In the following tables, the number near of the symbol ‘●’ indicates the SW revision of the DMG starting from which the address is supported by the protocol.
TABELLA 4: TABLE 4:
EVENTI EVENTS
 La data - ora viene letta in modalità compressa con formato unsigned long. Rappresenta il numero di secondi trascorsi a partire dal 01.01.1990 Per poter trasformare il dato in data e
ora corretta si po’ importare questo dato in una tabella Excel e applicare la seguente formula:
DATA EXCEL = (VALORE LETTO / 86400) + 32874
 Date and time are read in compressed mode with unsigned long format. It represents the number of seconds elapsed since 1.1.1990. To transform the data into the correct date and
time you can import this data into an Excel table and apply the following formula:
EXCEL DATE = (RETURNED VALUE / 86400) + 32874
Indirizzo
Address
WORDS
MISURA
MEASURE
UNITA’
UNIT
FORMATO FORMAT
DMG
110
210
DMG
300
DMG
700
DMG
800
DMG
900
DMG
6...
21D0H
1
PUNTATORE EVENTI
Indica l’ultimo evento registrato
EVENTS POINTER
Last event stored
Unsigned integer ●1
21D1H
1
CONTATORE EVENTI
Indica il numero totale eventi
EVENTS COUNTER
Total events stored
Unsigned integer ●1
3800H
1
EVENTO 1 DATA/ORA HMSB

EVENT 1 DATA/TIME HMSB

Unsigned integer ●1
3801H
1
EVENTO 1 DATA/ORA MSB

EVENT 1 DATE/TIME MSB

Unsigned integer ●1
3802H
1
EVENTO 1 DATA/ORA H LSB

EVENT 1 DATE/TIME HLSB

Unsigned integer ●1
3803H
1
EVENTO 1 DATA/ORA LSB

EVENT 1 DATE/TIME LSB

Unsigned integer ●1
3804H
1
LIBERO FREE Unsigned integer ●1
3805H
1
CLASSE EVENTO (tab. 5) EVENT CLASS (tab. 5) Unsigned integer ●1
3806H
1
TIPO EVENTO (tab. 5) EVENT TYPE (tab. 5) Unsigned integer ●1
3807H
1
CODICE EVENTO (tab. 6) EVENT CODE (tab. 6) Unsigned integer ●1
3808H
1
MISURA HMSB MEASURE HMSB Unsigned integer ●1
3809H
1
MISURA MSB MEASURE MSB Unsigned integer ●1
380AH
1
MISURA HLSB MEASURE HLSB Unsigned integer ●1
380BH
1
MISURA LSB MEASURE LSB Unsigned integer ●1
380CH
1
LIBERO FREE Unsigned integer ●1
380EH
1
LIBERO FREE Unsigned integer ●1
380EH
1
LIBERO FREE Unsigned integer ●1
380FH
1
LIBERO FREE Unsigned integer ●1
……….. Unsigned integer ●1
3E30H
1
EVENTO 100 DATA/ORA MMSB EVENT 100 DATA MMSB Unsigned integer ●1
3E31H
1
EVENTO 100 DATA/ORA MSB EVENT 100 DATA/TIME MSB Unsigned integer ●1
3E32H
1
EVENTO 100 DATA/ORA LSB EVENT 100 DATA/TIME LSB Unsigned integer ●1
3E33H
1
EVENTO 100 DATA/ORA LLSB EVENT 100 DATA/TIME LLSB Unsigned integer ●1
3E34H
1
LIBERO FREE Unsigned integer ●1
3E35H
1
CLASSE EVENTO (tab. 5) EVENT CLASS (tab. 5) Unsigned integer ●1
3E36H
1
TIPO EVENTO (tab. 5) EVENT TYPE (tab. 5) Unsigned integer ●1
3E37H
1
CODICE EVENTO (tab. 6) EVENT CODE (tab. 6) Unsigned integer ●1
3E38H
1
MISURA MMSB MEASURE MMSB Unsigned integer ●1
3E39H
1
MISURA MSB MEASURE MSB Unsigned integer ●1
3E3
A
H
1
MISURA LSB MEASURE LSB Unsigned integer ●1
3E3BH
1
MISURA LLSB MEASURE LLSB Unsigned integer ●1
3E3CH
1
LIBERO FREE Unsigned integer ●1
3E3DH
1
LIBERO FREE Unsigned integer ●1
3E3EH
1
LIBERO FREE Unsigned integer ●1
3E0FH
1
LIBERO FREE Unsigned integer ●1
