Doc. I317IGB12_19.doc 18/12/2019 P. 18 / 41
TABELLA 5: TABLE 5:
EVENTI: EVENTS:
Indirizzo
Address
CLASSE EVENTO
TIPO EVENTO
SORGENTE
SOUCE
EVENT CLASS
EVENT TYPE
0 POWER 0- POWER ON
1- POWER DOWN
2- REBOOT
POWER 0- POWER ON
1- POWER DOWN
2- REBOOT
1 MISURA (tab 6) 0- HIGH
1- LOW
2- MAX DEMAND
MEASURE (tab 6) 0- HIGH
1- LOW
2- MAX DEMAND
2
ALLARME
0- INIZIO ALLARME
1- FINE ALLARME
2- RESET ALLARME
ALLARM
0-
A
LARM BEGIN
1- ALARM END
2- ALARM RESET
3
LIMITE
0- LIMITE ON
1- LIMITE OFF
2- RESET ALLARME
LIMIT
0- LIMIT ON
1- LIMIT OFF
2- ALARM RESET
4
REMOTO
0- COMANDO REMOTO ON
1- COMANDO REMOTO OFF
REMOTE
0- REMOTE COMMAND ON
1- REMOTE COMMAND OFF
5 COMUNICAZIONE 0- COMUNICAZIONE ON
1- COMUNICAZIONE OFF
COMMUNICATION 0- COMMUNICATION ON
1- COMMUNICATION OFF
6
TARIFFE
0- CAMBIO TARIFFA
TARIFF
0- TARIFF CHANGE
7 SETUP 0- MENU PARAMETRI
1- MENU CUSTOM
2- MENU COMANDI
SETUP 0- PARAMETERS MENU
1- CUSTOM MENU
2- COMMAND MENU
8
MENU COMANDI
0-
A
ZZERA HI
–
LOW
1- AZZERA MAX DEMAND
2- AZZERA ENERGIA PARZIALE
3- AZZERA CONTORE PARZIALE
4- AZZERA CONTATORI
5- AZZERA TARIFFE
6- AZZERA ALLARMI
7- AZZERA LIMITI
8- AZZERA ENERGIA MENSILE
9- AZZERA ENERGIA TOTALE
10- AZZERA CONTAORE TOTALE
11- SETUP A DEFAULT
12- SALVA COPIA SETUP
13- RIPRISTINA SETUP
14- TEST COLLEGAMENTO
15- TOUCH SCREEN CALIBRATION
16- AZZERA EVENTI
17- AZZERA CONTATORI EN50160
18- AZZERA MEMORIA EN50160
COMMAND
MENU
0- RESET HI
–
LOW
1- RESET Max Demand
2- RESET PARTIAL ENERGYe
3- RESET PARTIAL COUNTERS
4- RESET COUNTERS
5- RESET TARIFF
6- RESET ALARMS
7- RESET LIMITS
8- RESET MONTHLY ENERGY
9- RESET TOTAL ENERGY
10- RESET TOTAL COUNTER
11- SETUP TO DEFAULT
12- SAVE SETUP
13- RESTORE SETUP
14- WIRING TEST
15- TOUCH SCREEN CALIBRATION
16- RESET EVENTS
17- RESET EN50160COUNTERS
18- RESET EN50160 MEMORY
9 PASSWORD 0- PASSWORD UTENTE
0- PASSWORD AMMINISTRATORE
PASSWORD 0- USER PASSWORD
0- ADMINISTARTOR PASSWORD
10 CONFIGURAZIONE 0- CAMBIO CONFIGURAZIONE MODULI CONFIGURATION 0- CHANGE MODULE CONFIGURATION
11 DIP SWITCH 0- CAMBIO CONFIGURAZIONE SWITCH DIP SWITCH 0- CHANGE SWITCH CONFIGURATION
12 QUALITA’ ENERGIA
EN50160
0- TENSIONE ALTA ON
1- TENSIONE ALTA OFF
2- TENSIONE BASSA ON
3- TENSIONE BASSA OFF
4- THD ON
5- THD OFF
6- ASIMMETRIA ON
7- ASIMMETRIA OFF
8- FREQUENZA ALTA ON
9- FREQUENZA ALTA OFF
10- FREQUENZA BASSA ON
11- FREQUENZA BASSA OFF
12- LIVELLO ARMONICHE ON
13- LIVELLO ARMONICHE OFF
14- DIP ON
15- DIP OFF
16- SWELL ON
17- SWELL OFF
18- INTERRUZIONE ON
19- INTERRUZIONE OFF
20- NVHI ON
21- NVHI OFF
22- NVLO ON
23- NVLO OFF
24- NFHI ON
25- NFHI OFF
26- NFLO ON
27- NFLO OFF
VLN O VLL
AVARAGE 10MIN
PAR P01.07
0- HIGH VOLTAGE ON
1- HIGH VOLTAGE OFF
2- LOW VOLTAGE ON
3- LOW VOLTAGE OFF
4- THD ON
5- THD OFF
6- ASYMMETRY ON
7- ASYMMETRY OFF
8- HIGH FREQUENCY ON
9- HIGH FREQUENCY OFF
10- LOW FREQUENCY ON
11- LOWFREQUENCY OFF
12- HARMONIC LEVEL ON
13- HARMONIC LEVEL OFF
14- DIP ON
15- DIP OFF
16- SWELL ON
17- SWELL OFF
18- INTERRUPTION ON
19- INTERRUPTION OFF
20- NVHI ON
21- NVHI OFF
22- NVLO ON
23- NVLO OFF
24- NFHI ON
25- NFHI OFF
26- FLO ON
27- NFLO OFF
THD
AVARAGE 10MIN
A
SY VLN O VLL
AVARAGE 10MIN
PAR P01.07
FREQUENCY
AVARAGE 10MIN
HARMONIC
LEVEL
VLN O VLL
AVARAGE 10MIN
PAR P01.07
FREQUENCY
AVARAGE 10MIN
