Doc. I317IGB12_19.doc 18/12/2019 P. 19 / 41
Il numero massimo eventi memorizzati è 100 (buffer circolare).
The max events number stored is 100 (circular buffer).
TABELLA 6:
CODICE EVENTO
EVENT CODE
MISURA
MEASURE
UNITA’
UNIT
0 V L1-N V/100
1 V L2-N V/100
2 V L3-N V/100
3 I L1
A
/10000
4 I L2
A
/10000
5 I L3
A
/10000
6 V L1-L2 V/100
7 V L2-L3 V/100
8 V L3-L1 V/100
9 W L1 W/100
10 W L2 W/100
11 W L3 W/100
12 var L1 var/100
13 var L2 var/100
14 var L3 var/100
15 VA L1 VA/100
16 VA L2 VA/100
17 VA L3 VA/100
18 PF L1 /10000
19 PF L2 /10000
20 PF L3 /10000
21 COSPHI L1 /10000
22 COSPHI L2 /10000
23 COSPHI L3 /10000
24 Hz /1000
25 V L-N EQV V/100
26 V L-L EQV V/100
27 I EQV
A
10000
28 W TOT W/100
29 var TOT Var/100
30 VA TOT VA/100
31 PF TOT /10000
32
A
SY VL-L %/100
33
A
SY VL-N %/100
34 UNBAL. I %/100
35 I N
A
/10000
36 LIBERO/FREE LIBERO/FREE
37 LIBERO/FREE LIBERO/FREE
38 LIBERO/FREE LIBERO/FREE
39 LIBERO/FREE LIBERO/FREE
40 LIBERO/FREE LIBERO/FREE
41 THD V L1 %/100
42 THD V L2 %/100
43 THD V L3 %/100
44 THD I L1 %/100
45 THD I L2 %/100
46 THD I L3 %/100
47 THD V L1L2 %/100
48 THD V L2L3 %/100
49 THD V L3L1 %/100
50 THD V L4 %/100
51 THD I L4 %/100
52 V L3-N V/100
53 I L4
A
/10000
54 LIBERO/FREE LIBERO/FREE
55 LIBERO/FREE LIBERO/FREE
56 LIBERO/FREE LIBERO/FREE
57 LIBERO/FREE LIBERO/FREE
58 LIBERO/FREE LIBERO/FREE
59 LIBERO/FREE LIBERO/FREE
60 LIBERO/FREE LIBERO/FREE
61 LIBERO/FREE LIBERO/FREE
62 LIBERO/FREE LIBERO/FREE
63 LIBERO/FREE LIBERO/FREE

Per Allarmi,limiti,comando remoto,tariffe, selezione menù comandi, il codice evento indica il relativo numero/canale associato.
For Alarms,limits,remote comand, command menu selection, the event code indicates the associated number/channel
.
Es:
Classe evento 3 = Limite + Codice evento 4 = Limite 4
Event class 3 = Limit + Event code 4 = Limit 4
