Lovato GEX69 C Series User Manual

I451 I GB D F E 10 16 4257Z010
I
19
Commutatore
GE0160E/T4 - GE0200E/T4 + GEX690C
247 30
145
250
83
60
94
GE0201E/T4 - GE0400E/T4 + GEX691C
260 30
216 223
121
310
Allegato 3:
SCHEMI ELETTRICI
COMMUTATORE I - 0 - II
12 3 75910486
AUT
IN (0) IN (1) IN (2)
230 VAC/DC
+5VDC
GND 1GND 2
OUT OUT
AUT
Go
to 0
Go
to 1
Go
to 2
POWER
SUPPLY
12 3 75910486
AUT
IN (0) IN (1) IN (2)
230 VAC/DC
+5VDC
GND 1GND 2
OUT OUT
AUT
Go
to 0
Go
to 1
Go
to 2
Imax = 120 mA
Vmax = 315 VAC/DC
Imax = 500 mA
Vmax = 40 VAC/DC
POWER
SUPPLY
Cablaggio proposto per alimentazione continua esterna K1, K2 = 230VAC = Bobina 230VAC
Relè K1, K2 interbloccati elettricamente e meccanicamente
A1
A2
A1
A2
K1 K2
21
21
11 21 31 31 21 11
12 24 34 34 24 12
CONNECTOR
mains
secondary
sources
