Lovato GEX69 C Series User Manual

I451 I GB D F E 10 16 4257Z010
D
30
Schaltgerät
GE0160E/T4 - GE0200E/T4 + GEX690C
247 30
145
250
83
60
94
GE0201E/T4 - GE0400E/T4 + GEX691C
260 30
216 223
121
310
Anlage 3:
SCHALTPLÄNE
SCHALTER I - 0 - II
12 3 75910486
AUT
IN (0) IN (1) IN (2)
230 VAC/DC
+5VDC
GND 1GND 2
OUT OUT
AUT
Go
to 0
Go
to 1
Go
to 2
POWER
SUPPLY
12 3 75910486
AUT
IN (0) IN (1) IN (2)
230 VAC/DC
+5VDC
GND 1GND 2
OUT OUT
AUT
Go
to 0
Go
to 1
Go
to 2
Imax = 120 mA
Vmax = 315 VAC/DC
Imax = 500 mA
Vmax = 40 VAC/DC
POWER
SUPPLY
Für einen Dauerbetrieb im Außenbereich empfohlene Verkabelung K1, K2 = 230 V ac = Spule 230 Vac
Relais K1, K2 elektrisch und mechanisch verriegelt
A1
A2
A1
A2
K1 K2
21
21
11 21 31 31 21 11
12 24 34 34 24 12
CONNECTOR
mains
secondary
sources
