SET COMPONENTS
Fig. 1 – PROLACTIS SET PARTS
1. Electric Pump main unit
2. AC adapter
3. Vacuum tube with adaptors
4. Expression collection combo kit
5. Food storage kit
a. Screw cap
b. Soft sealing disc
c. Hood/cup with scale
6. Breast Pump LOVI Protect Parts (for manual pumping)
a. Adjusting valve stem
b. Diaphragm
c. Handle
d. Diaphragm cover
7. Spare parts
a. One-way valve - 2 pcs
b. O-ring - 2 pcs
c. Let-down silicone cushion – 1 pc
d. Diaphragm (for electric pump) – 1 pc
8. Prolactis storing case
9. Disposable Breast Pads LOVI ‘Day&Night’ – 10 pcs
Fig. 2 – EXPRESSION COLLECTION COMBO KIT
1. Cap
2. Diaphragm
3. Cup with o-ring
4. Let-down silicone cushion
5. Breastshield body
6. One-way valve
7. Bottle adapter
8. Bottle
Fig. 3 – ELECTRIC PUMP MAIN UNIT
1. LCD screen
2. Vacuum adjusting wheel
3. Let-down button
4. M button
5. On/O button & power LED
6. Battery cover
7. Tubing adapter inlet
8. AC adapter inlet
Fig. 4 – LCD SCREEN GUIDE
1. Suction level indicator
2. Stimulation cycle indicator
3. Expression cycle indicator
4. Time indicator
5. Power indicator
6. M icon (memory)
7. Alarm
