Lowrance HOOK2 Guide

Overlay data
The data type can be changed, and the item position on the image is
selectable.
The data items can be turned on/o from the System Controls dialog.
Each data item can be removed individually from the panel:
1. Select the Edit overlay option in the System Controls dialog to turn
the unit into edit mode
2. Press the Menu/Enter key to display edit options
3. Press the X key to leave edit mode
Stopping the sonar
Use the Stop Sonar option in the System controls dialog to stop the
transducer from pinging without turning the unit o.
Creating a Man Over Board (MOB) waypoint
Activate a MOB waypoint by pressing both Zoom keys simultaneously.
Settings dialogs
Used for system conguration.
Learn more about marine electronics and navigation we have.

Lowrance HOOK2 Specifications

General

Waterproof Rating	IPX7
Operating Temperature	-15°C to 55°C (5°F to 131°F)
Sonar Type	CHIRP
Frequency	200kHz
Power Output	200 W (RMS)
Depth Capability	Up to 500 ft (152 m)
GPS	Yes (on some models)
Weight	Varies by model
Display Size	4" or 5" or 7"
