Lowrance Link-2 - 4-6-8 Turn GPS ENABLE On;Off; 4-6-9 Set Magnetic Variation (MAG VAR)

Lowrance - Link-2 Installation and Operation Instructions 33
4-6-8 Turn GPS ENABLE on/off
You can choose to turn the built in GPS function on/o.
SETUP
COG/SOG ▲
GPS ALERT
►GPS ENABLE▼
GPS ENABLED
►ON
OFF
1. Select GPS/DATA, then SETUP.
2. Move the cursor to GPS ENABLE and press ENTER.
3. Select ON/OFF as desired, in this example, ON has been selected, so the built in GPS
is turned ON.
4-6-9 Set Magnetic Variation (MAG VAR)
SETUP
GPS ALERT ▲
GPS ENABLED
►MAG VAR
MAG VAR
00.0
°W AUTO
MAG VARIATION
XX.X
°W (OR E)
SAVE
►YES
NO
AUTO
1. Select GPS/DATA, then SETUP.
2. Select MAG VAR.
3. Press ENTER to select the rst digit to adjust. Use CH / to adjust the MAGNETIC
dierence between true and variation, then press ENTER to conrm selection.
4. Select YES to save your changes.
Note: AUTO MAG VAR default is 00.0 for TRUE.
Note: W is the default and tenths of a degree is required.
