Lowrance SIMRAD S3100 - Technical Specifications; Environmental and Electrical Ratings; Physical and Interface Details; Additional Information

Technical specications
The future of our waters matters. That's why the S3100 sonar module is manufactured using recycled plastics, as part
of our ongoing commitment to sustainability.
More information
Document version: 001
For the latest version of this document in supported languages and other related documentation, visit
www.simrad-yachting.com/downloads/S3100.
Safety, disclaimer, and compliance
This product's safety, disclaimer, and compliance statements are supplied as a separate document.
Warranty
This product's warranty is supplied as a separate document.
Trademarks
®Reg. U.S. Pat. & Tm. Off, and ™ common law marks. Visit www.navico.com/intellectual-property to review the global
trademark rights and accreditations for Navico Group and other entities.
Copyright
© 2023 Navico Group. All Rights Reserved. Navico Group is a division of Brunswick Corporation.
Environmental
Operating temperature -15° C to 55° C (5° F to 131° F)
Storage temperature -20° C to 60° C (4° F to 140° F)
Waterproof rating IPX6 and IPX7
Electrical
Supply voltage 12 - 24 V DC (10.5 - 31.2 V DC)
Recommended fuse rating 5 A
Reverse polarity protection Yes
Power consumption (maximum) Max: 0.8 A; Typical: 0.6 A; Inrush: 3 A pk; >2.5 A for < 0.5 ms
Physical
Dimensions See mounting template
Weight 0.9 kg (1.9 lbs)
Compass safe distance 0.13 m (5.1 in)
Interface/connectivity
Sonar 1 port sonar
9-pin XSonic
®
(blue)
Sonar Low, Medium, and High CHIRP up to 1 kW
DownScan 455 kHz, 800 kHz, 700 kHz CHIRP, 1200 kHz CHIRP
SideScan No
1 port imaging
9-pin XSonic
®
(black)
Sonar Low, Medium, and High CHIRP up to 1 kW
DownScan 455 kHz, 800 kHz, 700 kHz CHIRP, 1200 kHz CHIRP
SideScan 455 kHz, 800 kHz, 455 kHz CHIRP, 1075 kHz CHIRP
Ethernet 1 port (5-pin)
1 port (12-pin)
