3
StructureScan Transducer Mounts
Transom Mount
(Page 6)
Keeps transducer in the water when the boat is •
on plane, allowing you to track bottom at high
speeds
Transducer angle can be adjusted so it is parallel •
with the water
Transducer more likely to collide with obstructions •
in the water and adds drag to the boat
Jackplate Mount
(Page 7)
Transducer is not in the water when boat is on •
plane; protects transducer and prevents drag
from transducer
Transducer angle can be adjusted so it is parallel •
with the water
Allows you to mount transducer without drilling •
holes in your boat
Does not track bottom when boat is on plane•
Step Mount
(Page 8)
Transducer is not in the water when boat is on •
plane; protects transducer and prevents drag
from transducer
Transducer angle can be adjusted so it is parallel •
with the water
Does not track bottom when boat is on plane•
Direct Mount/Step
(Page 9)
Transducer is not in the water when boat is on •
plane
Protects transducer and prevents drag from •
transducer
Transducer angle can not be adjusted so it is •
parallel with the water
Does not track bottom when boat is on plane•
Trolling Motor Mount
(Sold separately)
(Page 10)
Allows you to scan areas by moving trolling •
motor left/right
Can only be used when trolling motor is in the •
water
Rotating trolling motor quickly will impact sonar •
images
