LS Industrial Systems iS7 User Manual

iS7 Ethernet Option Manual
13
Set
Value
Input Instance
Data Size
The number
or Parameter
9 146 12 6
10 147 14 7
11 148 16 8
(7) CIP Output Instance(COM-17)
This parameter is shown only when the protocol has been set up with
the Ethernet IP sets up the format of the inverter reference data which
are sent by the Client (Originator) to the inverter for inverter control
during the I/O communication of CIP (Common Industrial Protocol). See
the Assembly Object section of the Ethernet IP.
(8) Para Status (COM-30~38)
This parameter is not used in case of Modbus TCP.
This parameter appears only when the set value of the Input Instance
(COM-17) in the Ethernet IP is 4 or above.
COM-30 Para Status Num cannot be set up but the number of the set
up parameters of the instance is shown. Enter the address of the
inverter data at the same number as that of the said parameters in the
COM-31~38.
Set
Value
Input
Instance
Data
Size
The number
of Parameter
0 20 4 X
1 21 4 X
2 100 4 X
3 101 4 X
4 121 2 1
5 122 4 2
6 123 6 3
7 124 8 4
8 125 10 5
9 126 12 6
10 127 14 7
11 128 16 8
