PARTS
OM 0472SB-A
[23]
CHUTE WITH HYDRAULIC ROTATION
REF. DESCRIPTION QTY PART #
1 Chute assembly w/decals 1 669681
2 Chute 1 669703
3 Knob 5/16"NC 2 657309
4 Flat washer nylon 11/32" dia. 2 658467
5 Carriage bolt 5/16"NC x 1" gr.5 PTD 2 0300003
6 Flat washer nylon 7/16" dia. 2 658468
7 Hand guard PTD 1 657308
8 Bolt hex. 1/4"NC x 3/4" gr.5 PTD 5 0100003
9 Flat washer 1/4" (5/16" hole) PTD 3 1400002
10 Lockwasher 1/4" PTD 5 1200002
11 Nut hex. 1/4"NC PTD 4 0900001
12 Rotation bushing 1 659151
13 Spacer for retaining plate 4 665957
14
Spacer for retaining plate
4 666191
15
Side retaining plate 2 669496
16
Middle retaining plate 1 669497
17
Bolt hex. 5/16" NC x 1 1/2", gr.5 PTD 8 0100021
18
Lockwasher 5/16", PTD 8 1200003
19
Nut 5/16" NC, PTD 8 0900002
20
Hydraulic motor 50CC 1 3910092
-
- Seal kit for motor 1 3910093
21
Woodruff key 1/4" x 1" #808 1 659191
22
Motor spacer 1 669718
23
Gear shield 1 669715
24
Motor gear 12 teeth 1 669705
25
Hose 1/4" x 103", 3/8NPT RM x 9/16JIC PVF 2 3700052
26
Connector restrictor 7/8ORB M x 9/16JIC M 2 664362
27
Female quick coupler 3/8”NPT 2 26001110
28
RED Dust cap 1 2600257
29
Blue Dust cap 1 2600258
30 Bolt 3/8" NC X 1", gr.5 PTD 4 0100038
31
Lockwasher 3/8", PTD 4 1200004
32
Flat washer 3/8" (7/16" hole) PTD 4 1400004
