PARTS
OM 0472SB-A
[25]
SNOWBLOWER ASSEMBLY (FRONT)
REF. DESCRIPTION QTY PART #
1 Housing 1 669772
2 Left auger 1 660376
3 Right auger 1 660377
4 Bearing 2 4300118
5 Gearbox 1 4500137
6 Gearbox support 1 665842
7 Fan 1 665998
8 Shear plate 1 665999
9 Skid shoe 2 669586
10 Cutting edge 1 659531
11 Bushing (oilite) 2 4300057
12 Key 1/4" x 1/4" x 2"
2 658188
13 Key 1/4" x 1/4" x 1 1/4" 1 654643
14 Reinforcement plate 1 654468
15 Bolt hex. 3/8" NC x 1 1/4" gr.5 PTD 2 0100039
16 Flat washer 3/8" (7/16" hole) PTD 2 1400004
17 Bolt hex. 1/2" NC x 1" gr.5 PTD 4 0100068
18 Lockwasher 1/2" PTD 12 1200006
19 Flat washer 1/2" (9/16" hole) PTD 4 1400006
20 Carriage bolt 3/8" NC x 1" gr.5 PTD 4 0300008
21 Nut hex. 3/8" NC PTD
6 0900003
22 Plow bolt 3/8" NC x 1 1/4" gr.5 PTD 8 0400002
23 Stover locknut 3/8" NC PTD 8 1100003
24 Bolt hex. 1/2" NC x 1 1/2" gr.5 PTD 8 0100070
25 Nut hex. 1/2" NC PTD 8 0900006
26 Bolt hex. 5/16" NC x 2 1/2" gr.5 PTD 1 0100026
27 Nylon insert locknut 5/16" NC PTD 1 1000005
28 Shear bolt 5/16" NC x 1 1/4" incl. lock & nut 1 665548
29 Shear bolt 5/16" x 2 1/2" incl. lock & nut 2 657296
30 Grease fitting 1/4" NF 2 654106
31 Lockwasher 3/8" PTD
6 1200004
32 Output shaft 1 654505
33 Woodruff Key 1/4" X 1 1/8lg 1 654506
