3 -19
PTO switch
(9) PTO switch (Independent PTO)
The engine starts only when the PTO switch is
placed in “OFF” position for safety.
After starting engine, you must comply with the
following instructions.
1. Check the safety conditions around the
implement.
2. Place the PTO gear lever(if fitted) to the desired
position.
3. Push and turn the PTO switch to “ON” position
to operate the PTO shaft.
4. When the PTO shaft begins to rotate, the PTO
operation indicator on the instrument panel will
be turned on.
5. If you want to stop the PTO shaft temporarily,
push the PTO switch to “OFF” position.
ON : PUSH AND TURN
OFF : PUSH
▶ Before attaching, detaching or checking the PTO driven equipment, always place
the PTO switch in “OFF” position, and PTO gear lever(if fitted) in neutral position.
▶ Even if depressing the clutch pedal or lifting up the 3-point linkage to the upper
limit, the PTO shaft will not be stopped. Pay attention to the surroundings to prevent
an accident.
▶ Do not engage the PTO clutch at high engine speed. Sudden engagement can
cause damage to the implement and PTO clutch. Engage the PTO at low idle rpm,
and then raise the engine speed up.
Warning
