iP5A Modbus/TCP Manual
10
Frame Constitution that Server responds to Master
③ Write Multiple Register
The function is used when modifying consecutive Data from 1 up to 16 of
inverter (Server).
Frame Constitution that Client requires Server
Frame Constitution that Server responds to Master
Responded Frame
Length
Value
Function Code
1 Bytes
0x06
Comm. Address
2 Bytes
0x0000 ~ 0xFFFF
Data Value
2 Bytes
0x0000 ~ 0xFFFF
Required Frame
Length
Value
Function Code
1bytes
0x10
Comm. Address
2bytes
0x0000 ~ 0xFFFF
Modifying Data number
2byte
1~16 (by LSIS inverter
standard )
Byte Count
1byte
2 X Data number
Data value to be
modified
Data number
x 2 bytes
Data for modifying
Responded Frame
Length
Value
Function Code
1 Bytes
0x10
Comm. Address
2 Bytes
0x0000 ~ 0xFFFF
Modifying Data
number
2 Bytes
1~16 (by LSIS inverter
standard)
