10. LED Information
In Modbus/TCP communication card, 4 LEDs which indicate the Modbus/TCP state
to the user are installed. In iP5A Modbus/TCP communication card, LEDs are
displayed as below.
Type
Code
Description
ILLEGAL FUNCTION
0x01
If non-supported Function is
Required, this massage is displayed.
ILLEGAL DATA ADDRESS
0x02
If Data of not used address is
required or to be modified, this
massage is displayed.
ILLEGAL DATA VALUE
0x03
If you try to modify Data with the
Value that is against the permitted
Data range, this massage is
displayed.
SLAVE DEVICE FAILURE
0x04
If there is error in Server
(CAN Comm. ERROR with inverter,
Option initialization ERROR, failure
of DATA comm. with inverter), this
massage is displayed.
SLAVE DEVICE BUSY
0x06
If Server can’t respond due to other
process (such as Inverter parameter
initialization or option initialization
setting), this massage is displayed.
READ ONLY ADDRESS
0X14
If you try to save address that is
only for reading value, this massage
is displayed.
WRITE PERMITION ERROR
0x20
This Code only exists at LS inverter.
If you try to modify modifying
prohibited parameter value this
massage is displayed.
Green
Speed
Green
Link
Red
Error
Green
CPU
