iP5A Modbus/TCP Manual
2
1. Introduction
Modbus/TCP communication board make SV-iP5A inverter be connected to Ethernet
network. Controlling and monitoring inverter can be done by PLC sequence program or any
Master Module. Since Ethernet which constitutes Internet has been used and IPV4 has been
supported, wherever Internet can be done, controlling and monitoring is possible. But,
Ethernet network of the factory has to be connected to Internet through Gateway.
With simple wiring, installation time can be reduced and maintenance becomes easier.
2. Modbus/TCP Technical features
3. Product Constituents
-. Modbus TCP communication board : 1 ea
-. Supporting pole : 3 ea
-. The manual : 1 ea
Transmission Speed
10Mbps, 100Mbps
Transmission method
Baseband
Max. extended distance
between nodes.
100m (Node-Hub)
Max. node number
Hub connection
Auto Negotiation
Supported
Max. Frame size
1500 byte
Communication zone access
method
CSMA/CD
Frame error checking method
CRC32
Recommended
connecting channel
3 channel
