iP5AiP5A
Grounding
Terminal Configurations (Power Circuit Terminal)
Drive Capacity Grounding wire Sizes, AWG or kcmil (mm
2
)
kW HP 200V Class 400V Class 600V Class
5.5 ~ 7.5 7.5 ~ 10 10 (5.5) 12 (3.5) 14 (2.5)
11 ~ 15 15 ~ 20 6 (14) 8 (8) 12 (3.5)
18.5 ~ 30 25 ~ 40 4 (22) 6 (14) 8 (8)
37 ~ 55 50 ~ 75 - 4 (22) 6 (14)
75 ~ 90 100 ~ 125 - 2 (38) 4 (22)
110 ~ 132 150 ~ 200 - 1/0 (60) 2 (38)
160 ~ 280 250 ~ 350 - 4/0 (100)
315 ~ 375 400 ~ 600 - 300 (150)
450 700 - 400 (200)
* Apply the rated torque to terminal screws. * Loose screws can cause of short circuit or malfunction. Tightening the screw too much can damage the terminals and cause a short circuit or malfunction.
* Use copper wires only with 600V, 75
℃
ratings. For 7.5~11kW 240V type drives, R(L1), S(L2), T(L3) and U, V, W terminals are only for use with insulated ring type connector.
200V
Class
400V
Class
600V
Class
Wires & Terminal lugs
Refer to below for wires, terminal lugs, and screws used to connect the drive power input and output.
Wire size
Drive capacity
Terminal
Screw torque
R(L1), S(L2), T(L3) U, V, W
screw size
Kgf·cm Ib·in mm
2
AWG or
mm
2
AWG or
kcmil kcmil
7.1 ~12.2 6.2 ~10.6 2.5 14 2.5 14
7.1 ~12.2 6.2 ~10.6 2.5 14 2.5 14
7.1 ~12.2 6.2 ~10.6 2.5 14 2.5 14
7.1 ~12.2 6.2 ~10.6 4 12 4 12
7.1 ~12.2 6.2~10.6 5.5 10 5.5 10
24.5 ~31.8 21.2~27.6
8 8 8 8
14 6 14 6
30.6 ~38.2 26.6~33.2
22 4 22 4
38 2 38 2
61.2 ~91.8 53.1~79.7
38 2 38 2
60 1/0 60 1/0
7.1 ~12.2 6.2 ~10.6 2.5 14 2.5 14
7.1 ~12.2 6.2 ~10.6 2.5 14 2.5 14
7.1 ~12.2 6.2 ~10.6 2.5 14 2.5 14
7.1 ~12.2 6.2 ~10.6 2.5 14 2.5 14
3.5 12 3.5 12
7.1 ~12.2 6.2~10.6 3.5 12 3.5 12
5.5 10 5.5 10
30.6~38.2 26.6~33.2
8 8 8 8
14 6 14 6
61.2~91.8 53.1~79.7
22 4 22 4
38 2 38 2
89.7~122.0 77.9~105.9 60 1/0 60 1/0
100 4/0 100 4/0
150 300 150 300
200 400 200 400
182.4~215.0 158.3~186.6 250 500 250 500
325 700 325 700
2×200 2×400 2×200 2×400
2×250 2×500 2×250 2×500
3.5 12 3.5 12
7.1 ~12.2 6.2~10.6 3.5 12 3.5 12
5.5 10 5.5 10
30.6~38.2 26.6~33.2
8 8 8 8
14 6 14 6
61.2~91.8 53.1~79.7
22 4 22 4
38 2 38 2
89.7~122.0 77.9~105.9 60 1/0 60 1/0
182.4~215.0 158.3~186.6 100 4/0 100 4/0
M4
M4
M4
M4
M4
M5
M5
M6
M6
M8
M8
M4
M4
M4
M4
M4
M4
M4
M6
M6
M8
M8
M10
M12
M12
M12
M12
M12
M12
M12
M4
M4
M4
M6
M6
M8
M8
M10
M12
0.75kW(1HP)
1.5kW(2HP)
2.2kW(3HP)
3.7kW(5HP)
5.5kW(7.5HP)
7.5kW(10HP)
11kW(15HP)
15kW(20HP)
18.5kW(25HP)
22kW(30HP)
30kW(40HP)
0.75kW(1HP)
1.5kW(2HP)
2.2kW(3HP)
3.7kW(5HP)
5.5kW(7.5HP)
7.5KW(10HP)
11 kW(15HP)
15 kW(20HP)
18.5kW(25HP)
22~30kW(30~40HP)
37~55kW(50~75HP)
75~90kW(100~125HP)
110~132kW(150~200HP)
160kW(250HP)
220kW(300HP)
280kW(350HP)
315kW(400HP)
375kW(500HP)
450kW(600HP)
5.5kW(7.5HP)
7.5KW(10HP)
11 kW(15HP)
15 kW(20HP)
18.5kW(25HP)
22~30kW(30~40HP)
37~55kW(50~75HP)
75~90kW(100~125HP)
110~132kW(150~200HP)
18
