7ASSEMBLY INSTRUCTIONS |
IV. ASSEMBLY INSTRUCTIONS
1
51
34 35 74 44
67 47 46
45 55 50
5# Allen Wrench 5mm 1pc
FIXING TOOLS:
Do not turn on the power before completing the assembly.
When you open the carton, and you will find the below parts in the carton.
WARNING!
No. Description Specs Qty
1 Main frame 1
45 5# Allen Wrench 5mm 1
55 Bolt
M8*45
2
50 Bolt
M8*16
6
51 Lock washer 8 8
67 Bolt
4.2*19
2
No. Description Specs Qty
47 Wrench with screwdriver S =13, 14, 15 1
46 Water bottle M8*45 1
34 Left base cover
M6*15
1
35 Right base cover
M8*20
1
74 MP3 Wire Optional 1
44 Safety key 6 1
To Next Page
