34
23 Lock washer 10 8 71 Left base cover 1
24 Spring washer 6 4 72 Right base cover 1
25 Spring washer 8 2 73 Transport wheel 2
26
Screw
ST4.2*20
8
74
Foot Pad
4
27 Lock washer 8 6 75 Oil bottle 1
28 Screw ST4.2*20 22 76 Running board 1
29
Screw
ST4.2*25
4
77
DC motor
1
30 Screw ST4.2*9 12 78 Incline motor 1
31 Screw ST4.2*20 31 79 Single wire 1
32 Screw ST4.2*50 2 80 Pulse wire 2
33 Bolt M10*50 2 81 Control board 1
34 Bolt M10*45 4 82 Overload protector 1
35 Screw ST4.2*19 3 83 Computer top wire 1
36 Screw ST4.2*30 2 84 Computer bottom wire 1
37 Bolt M8*25 4 85 Magnetic ring 1
38
Bolt
M6*40
4
86
Switch
1
39 Bolt M8*45 2 87 Power socket 1
40 Bolt M6*15 4 88 Power wire 1
41 Bolt M8*65 3 89 Grounding wire 1
42 Bolt M8*40 2 90 AC Single wire 120mm 2
43 Bolt M8*42 5 91 AC Single wire 450mm 1
44 Bolt M8*25 1 92 Blue Single wire 1
45 Bolt M8*35 2 93
Running board
strengthen tube
2
46
Bolt
M8*20
4
94
Screw
ST2.9*8
1
47
Bolt
M8*30
2
95
Screw
ST2.9*6.
2
