LSG VULCAN M2 - 10. PARTS LIST

33
10. PARTS LIST
NO. DESCRIPTION SPECS. QTY NO. DESCRIPTION SPECS. QTY
1 Main frame 1 49 Bolt M10*55 1
2 Base frame 1 50 Distance sleeve 8
3 Incline frame 1 51 Cushion 4
4 Left upright 1 52 Isolation nylon pad 4
5 Right upright 1 53 Motor up cover 1
6 Computer bracket 1 54 Motor bottom cover 1
7 Panel assembly 1 55 Panel cover 1
8 Left rotating plate 1 56 Panel top cover 1
9 Right rotating plate 1 57 Panel bottom cover 1
10 Front roller 1 58 Computer top cover 1
11 Rear roller 1 59 Computer bottom cover 1
12 Cylinder 1 60 Left hand bar 1
13 Pulse metal plate 4 61 Right hand bar 1
14 5#Allen wrench 5mm 1 62 Safety key 1
15 6#Allen wrench 6mm 1 63 Pulse insert 2
16
Wrench with
screwdriver
1 64 Left back end cap 1
17 Lock nut M6 4 65 Right back end cap 1
18
Lock nut
M8
16
66
Side rail
2
19 Lock nut M10 6 67 Running belt 1
20 Flat washer 6 4 68 Motor belt 1
21 Flat washer 8 9 69 Moving wheel 2
22 Arc washer 8 4 70
strengthening tube
cushion
4
