LSG VULCAN M2 - 4. ASSEMBLY INSTRUCTIONS; Part List; Fixing Tools

7
4. ASSEMBLY INSTRUCTIONS
PART LIST
NO
DES.
Specification
Nos.
NO
DES.
Specification
Nos.
1
Main frame
1
16
Wrench with screwdriver
S =13, 14, 15
1
7
Panel assembly
1
39
Bolt
M8*45
2
71
Left base cover
1
40
Bolt
M6*15
4
72
Right base cover
1
46
Bolt
M8*20
4
88
Power Wire
1
28
Screw
ST4.2*20
4
75
Oil bottle
1
20
Flat washer
6
4
62
Safety key
1
22
Arc washer
8
4
14
5#Allen wrench
1
24
Spring washer
6
4
15
6#Allen wrench
1
FIXING TOOLS:
5# Allen Wrench 5mm 1pc
6# Allen Wrench 6mm 1pc
Wrench with screwdriver S =13, 14, 15 1pcs
Notice: Do not get turn on power before completing the assembly.
