LSI GC Series User Manual

6 The GS22X-XX Series Gateways
2.4 LSI WM Configurator
The LSI Wireless Gateway can be congured
using the
LSI WM Configurator software tool
on a personal computer (PC) connected to the
LSI Gateway by USB. Furthermore LSI WM
Configurator can be used to make data collected
by the
LSI Gateway accessible to data logging
applications on a PC connected to the
LSI
Gateway by USB or RS232. Initial conguration
of the
LSI Gateway may be easier prior to nal
physical installation depending on accessibility.
2.5 PC Installation
2.5a System Requirements
Windows 2000, XP, Vista (32/64bit) or Windows 7
(32/64bit).
2.5b LSI WM Configurator and USB
Driver Installation
Before starting installation, make sure that no
LSI Gateway is connected to the computer.
1. Download the installation file from www.
loadsystems.com/wmconfigurator.
2. Install the le and follow the steps from the
installation wizard.
When transferring the les, the installation
wizard will automatically execute the USB
driver installation; a Windows warning will
recommend to stop the installation, ignore
this warning and select Continue Anyway
(Windows XP) or Install this driver anyway
(Windows Vista, Windows 7).
2.5c LSI Gateway Connection
Windows Vista / Windows 7:
1. Connect the LSI Gateway to the computer;
the device will automatically be installed.
Windows XP:
1. Connect the LSI Gateway to the computer;
Found New Hardware Wizard will appear.
2. If Windows asks to connect to Windows
Update to search for software, select No, not
this time and then click Next.
3. Select Install the software automatically,
then click Next to continue.
4. A Windows warning indicating that the driver
has not been tested will recommend to stop
the installation, ignore this warning and select
Continue Anyway.
5. When the installation wizard has finished
installing the software, click Finish to close the
wizard.
When the installation is completed, the Device
Manager will appear as shown below:
WARNING! The system must be installed
in compliance with
LSI instructions and
using
LSI supplied components only. Failure
to install all parts, or replacing parts or
components with parts or components not
supplied by
LSI, may lead to system failure,
serious injury or death.
!
Figure: Device Manager, Windows Vista / Windows 7
Figure: Device Manager, Windows XP
