LSIS GIPAM 2000 - Page 33

33
Input/output terminal interface. (FI/M TYPE)
terminal number
Default use Available use
remark
output
output
CB2 status input(52a)
CB2 status input(52b)
Input for 63CB
Input for 43RC
GENERAL DI
Default
CB21status input(52a)
CB2 status input(52b)
Default
Ext.Reclosing init input
It is available only when user sets PO to
Trip in trip logic
user must set the wire when the 79(reclosing) relay
Elements used
79 sequence will start only when Logic high input
This contact can be used for variety use
This contact can be used for CB2 only when PO set
to Trip in trip logic
output
output
output
output
If 79(reclosing) was selected, the use of this
conatact will be changed.
