LSIS GIPAM 2000 - System Config

24
※ DI, DO function set is related with EVENT, FAULT. So user cant set up EVENT,
FAULT setting in some cases.
[CB2 or PO]
[RECLOSING
ON/OFF]
(It is used to control CB.)
PO (It is used for general
POWER OUT)
RECLOSING ‘ON’
RECLOSING ‘OFF’
(used for general DI.DO)
F
unction setting
DI, DO EVENT/FAULT saved function
EVENT: Default . This is unchangeable(52A,52B)
EVENT: user changeable
EVENT: user changeable
FAULT, EVENT: Default . This is unchangeable.
FAULT: Default . EVENT: user changeable
EVENT: Default . This is unchangeable(RCL function)
EVENT: Default . This is unchangeable(RCL function)
EVENT: user changeable. (RCL function on/off)
EVENT: user changeable
EVENT: user changeable
SYSTEM CONFIG
User can set up the system on SYSTEM CONFIG menu. And this menu displays
information of communication.
① child menu of SYSTEM CONFIG
Child menu
Function
Changeable menu: PT RATIO, CT RATIO, GPT RATIO, WIRNG TYPE, FREQUENCY
AUTO RESET ON/OFF
Changeable menu: I-NET ADDRESS, DNP ADDRESS, DNP BAUD RATE
Supervision menu: the type of communication card.(the type is displayed when the device
Powered on)
Changeable menu: trip relay checking on/off, the interval of checking, trip circuit
checking on/off
Changeable menu: device ID, TIME DATE
Supervision menu: the hardware version, MMI software information, DSP software
Information, the version of communication software, used period
1
11
1.
. .
. MMI
MMIMMI
MMI
Changeable menu : LCD contrast
