41
CB trip
coil
2) (on the output board) CB_OFF Relay contact.
It can supervise the CB1_OFF relay and CB2_OFF relay error at regularity interval.
If there is some error, system operates the DIGN_ERR contact and save the event
and also LCD displays the error. This function can be used by setting CB auto check
and setting the CB_OFF relay check interval value. And the check can be done by
manually.
ATTENTION) This function can be used only when the CB Trip Sequence is set up.
3. User interface
3. User interface3. User interface
3. User interface
