LSIS H100 User Manual

LSIS H100 Quick Start Guide
2 LS H100 Quick Start Guide
Rev I_6-19-2017
Table 3. HP to kW Conversion
3. RPM Entry
Table 4. Poles to RPM
RPM
3600
1800
1200
Poles
2
4
6
Example:
If actual motor RPM is 3450.
• Set Motor Poles = 2
• Set Slip RPM = 150 RPM
HP 1/4
1/2 1
1.5
2 3
5
7
10 15 20 25 30 40 50 60 75
100 125
150
200 225
250
300 350
400 500
600
kW
0.2
0.4
0.75
1.1
1.5
2.2
3.7
5.5
7.5 11.0 15.0 18.5 22.0 30.0 37.0 45.0 55.0 75 90 110 132 160
185 220
280 315
375
450
