Chapter 12 Memory Module
12-6
(6) Read from Memory module
(a) Set the mode switch of XBO-M2MB as “5” and connect XBO-M2MB to USB port of PC
(b) Select “Online Read from Memory module” on XG-PD menu.
(c) If you click “OK” button”, it read each parameter form the memory module.
-. “Open from memory module” and “Write to Memory module” menus of PADT are activated when
PLC is Offline. They are deactivated when PLC is Online.
-. When connecting with PADT, connection type should be „USB‟
To Next Page
